Electrical parameters:

1.Frequency range: 806-9600MHz 1710-2690MHz

2.Polarization: vertical

3.Gain:8.5±1dbi(806-960MHz) 9.5±1dbi(1710-2690MHz)

4.Horizontal half power beam width: 75±10°, 70±15°

5.Vertical half power beam width: 55°(806-960MHz), 50°(1710-2690MHz)

6.Front-to-back ratio:>15dB

7.VSWR: ≤1.5

8.Third order intermodulation: <-107dBm

9.Input impedance: 50Ω

10.Power capacity: 50W

11.Anti-lightning protection: DC ground

Basic mechanical performance:

1.Product category: N female

2.Size (without packet):410*210*65mm

3.Weight (without packet):1.0kg

4.Antenna shield material: ABS

5.Antenna shield color: white

6.Operating temperature: -30~+50℃

Product feature:

log-periodic antennas most be used at ultra-short wave frequency band, they can also be used as short-wave communication antenna and Medium wave, short wave broadcast transmission antenna. It has a high efficiency with an almost expected transmission value and better directivity, easy site construction and easy maintenance compared with other high gain antennas.
